Main features
Fully compatible with standard
microfluidics connectors
PFA material compatible with HF solutions
Enhanced sensitivity and stability
Widest range of operation in the market
0,01ml/min to 1 ml/min and 0,5 to 1,1 lpm of Ar
Universal ports ¼”-28, no proprietary
connectors
Specifications
| Specifications | HiNeb® |
|---|---|
| Sample flow rate | 0.01-1 ml.min-1 [best with 0.4] |
| Argon flow rate | 0.75 l.min-1 |
| Argon pressure | 150 kPa |
| Sample connection | Direct, 1/16” OD PFA tubing to 0.25 mm ID |
| Gas connector | Direct, 1/16” OD PFA tubing to 4 mm male |
| Spray chamber fit | Nebulizer body 6mm OD |
| Materials | PFA |
| Chemical compatibility | Aqueous, High TDS, HF acid and Organic Solvents |
| TDS handling capacity | 100 g/l |
| UNSPSC code | 41113000 |
